180PCS Deutsch Connector Pins and Sockets, Size 12 16 20 Male and Female Solid Terminals, Solid Contact Kit, Wire Range 12-22AWG, Compatible with Deutsch DTP, DT, DTM Series Connectors

Features

• Product List: Contains 180 pieces of Deutsch Pins and Sockets Kits, 20 pairs of size 12 terminal pins and Sockets, 35 pairs of size 16 terminal pins and Sockets, 35 pairs of size 20 terminal pins and Sockets, versatility ensures the right contacts for the different applications
• Size 12: 20 pairs of male and female terminals, wire gauge range 12-14 AWG; pin contacts 204, Socket contacts 203, max current rating 25A
• Size 16: 35 pair male/female terminals, wire gauge range 14-20 AWG; pin contacts 215, Socket contacts 209, max current rating 13A
• Size 20: 35 pair of male and female terminals, wire gauge range 20-22 AWG; pin contact 202, Socket contact 201, max current rating 7.5A
• High-quality materials: Materials are nickel-plated tin-bronze construction for greater stability and conductivity. Solid contacts are less prone to damage and have better conductivity, keeping the electrical performance stable
• Compatible Connectors: Deutsch Pin are compatible with Deutsch series connectors, DTP, DT, DTM series, HD30 series, HDP20 series, DRC series, DRB series, HD10 series, DTHD series, JIFFY SPLICE series, etc
• Versatile applications: Due to the compatibility, durability and versatility of the contact kits with Deutsch series connectors provide a reliable connection for a wide range of wire connections such as automobiles, RVs, motorcycles, trucks, marine and industrial applications.
