13.56mhz RFID USB Reader ISO14443A/B ISO 15693 Contactless Smart Card Reader (ISO 14443A/B+15693)

Interface:USB 2.0 Full Speed Device Power:From USB port Supported Operating Systems:Win XP/7/10/LUNIX,Android4.0 above Standard:ISO/IEC 14443 TypeA, TypeB , ISO/IEC 15693 Support the card type:Mifare Classic Protocols card, UltraLight, UltraLight C, T=CL CPU card, Ntag213, Ntag215, Ntag216, Mifare PLUS, DESfire, I-CODE2 Format:10 digit dec(Defoult output format) (Allow user to customize the output format by software) Smart Card Read Speed:106kbit/s Operating Distance:Up to 50 mm LED Status Indicators:2 LED (green and red) Dimensions:118mm (L) x 78mm (W) x 18mm (H) Weight: 150g Temperature:-10°C – 60°C Humidity:10% to 90%, non-condensing Method of installation and use 1. Connect with computer through USB interface directly. When the buzzer sounded, reader into the self-inspection. And the same time, LED turn into red means standby. 2. Open the output of computer software,such as Notepad\a word document or Excel sheets. 3. The mouse in Notepad or WORD document clicking. 4. Put tag on the top of reader, the software will output a data(card number) of the tag. When reading the tag, LED light change from red to green. Detecting device is connected Open the Device Manager of computer, If appears Humans Input Device that means Reader has successfully into computer. Precautions 1. Do not install the reader on the magnetic objects and metal objects, they will seriously affect the RF signal. 2. If after reading, the tag is still in the induction zone, the RF reader will not send data and without any hints. Common problems 1. Operation without feedback: Please check whether the interface plugged in, whether the tag is a valid or whether another RF tag is within the reading range. 2. Data error: Please check Whether the mouse is moved, whether the reader is in a critical state and whether the cable length is too long.
