12888 High Torque Clock Mechanism Replacement, 28mm Long Shaft

Additional Details from the Manufacturer

This item information is coming from the manufacturer. Some of the details may vary from the Nellis Auction listing. Please check the Quality Rating and Notes for information specific to this listing

More features

• HIGH TORQUE FOR OVERSIZED DIALS: drives minute hands up to 450 mm (17.7 in). The 12888 is a stepping quartz movement, so the hands advance once per second with a light tick. The torque is sized for the long, heavy hands that large wall clocks use, and the motor runs on one AA (LR6) battery.
• CHOOSE BY DIAL THICKNESS, NOT BY THE OLD MOVEMENT NUMBER. This option: 28 mm total shaft, 16 mm (5/8 in) thread, for 10-13 mm (25/64-33/64 in) dials. Measure the panel where the shaft passes through; thinner dials need the 18 mm or 23 mm shaft, and dials over 13 mm are not covered - see the size chart image.
• MOUNTING HARDWARE INCLUDED: iron hanging hook, rubber pad, washer and hex nut. No hands in this option, so check your existing pair: hour hand hole 5.03 mm (0.198 in) round, minute hand hole 4 mm (0.157 in) rectangular. Hour and minute hands only; battery not included.
• The hanging hook comes in the kit, so there is no separate part to source. Undo the old movement, slide the shaft through the dial, fit the rubber pad, washer and hex nut, then push the hands onto the shaft. A step-by-step video and a printed guide come with the kit.
• Not sure your old hands will fit? Send us a photo of the dial and the hand holes before you order and we will tell you which shaft size to take. DEEWISH has produced clock movements for 20 years, and if anything arrives wrong or stops running, message us and we will look into it.
