1 PC SHLPDFM Universal Steering Rag Joint 3/4" DD x 3/4" - 30 Spline Rag Joint Steering Coupler GM Power & Manual

Features

• ◆Principle and Function:It is always a good idea to replace the rag joint when doing any work on the steering system. Rag joints provide a small amount of flex for a steering shaft within a few degrees of the same plane as the steering gear input shaft. They also provide some damping of vibration coming from the steering system, providing some isolation for the steering wheel. These joints will wear over time, so replacing them is an inexpensive way to refresh the steering system.
• ◆Size:This includes both sides of the rag joint, not just one half .Steering Shaft Side: 3/4" DD;Steering Box Side: 3/4" - 30 spline.
• ◆Fitment:This rag joint is 3/4" DD x 3/4-30.One end is 3/4" DD which is a common shaft size found on steering columns and connecting shafts.The other end is a 3/4" - 30 spline. That spline size is found on some of the following applications:1968-1983 Corvette Manual Boxes;GM 525 Manual Steering Boxes;GM 605 Power steering boxes;Some Models of GM Racks;GM 700 Model Power Steering Boxes 1978 & Later Models;Some after market 500 and 600 series steering boxes.
• ◆High Quality Material:Made of High Quality Solid Billet Steel Material,maximum durability,Deformation resistance, high strength, good wear resistance, high hardness, long life.
• ◆Any questions, please contact us first.
